Watch ‘supernova machine’ mimic swirls from exploding stars

A new machine can mimic the swirls that the blast of a supernova explosion creates. Check out the show for yourself.

Ben Brumfield-Georgia Tech • futurity
June 18, 2020 9 minSource

A machine the size of a double door can replicate how supernovas paint astronomical swirls into existence, researchers say.

“It’s six feet tall and looks like a big slice of pizza that’s about four feet wide at the top,” says first author Ben Musci, a graduate research assistant at the Georgia Institute of Technology.

“We suddenly go from a perfectly still chamber to a little supernova.”

The supernova machine is also about as thin as a door and stands vertically with the point of the “slice of pizza” at the bottom.

A concise detonation in that tip thrusts a blast wave toward the top, and in the middle of the machine, the wave passes through two layers of gas, making them mix turbulently into swirls like those left by supernovas.

Laser light illuminates the swirls, and through a window, a high-speed camera with a close-up lens captures the beauty along with data on a centimeter scale that can be extrapolated to astronomical scales using well-established physics math. Getting the machine to produce results useful for studying nature took two and a half years of engineering adjustments.

Cosmic swirls

“We suddenly go from a perfectly still chamber to a little supernova. There was a lot of engineering done to contain the blast and at the same time make it realistic where it hits the gas interface in the visualization window,” says Devesh Ranjan, a professor in the George W. Woodruff School of Mechanical Engineering.

The supernova machine looks like an upside-down triangle mounted in a series of beams.
The lab machine that generates the miniature supernova remnants stands about six feet tall. At the bottom, a small detonation of an explosive sends the blast wave upward. It passes through the window in the center, where it jams layers of gas together to create turbulence. A high-speed camera captures the creation of the formations. (Credit: Georgia Tech)

“The hard part was troubleshooting the artifacts that were not part of supernova physics. I spent a year getting rid of things like an extra shock wave bouncing around in the chamber or air leaking in from the room,” says Musci. “I also had to make sure that gravity, background radiation, and temperature did not throw off the physics.”

Not all nebulas are remnants of supernovas, but many are. They and other supernova remnants start out with a massive star. Stars are balls of gases, which are arranged in layers, and when a star explodes in a supernova, those layers enable the formation of the beautiful swirls.

“On the outside, the gasses have low density and on the inside high density, and very deep in the star, the density begins to force the gases together to make iron in the star’s core,” Ranjan says.

“After this point, the star runs out of nuclear fuel, so the outward force caused by nuclear fusion stops balancing the inward gravitational force. The extreme gravitation collapses the star,” Musci says.

In the center of the star, there is a point explosion , which is the supernova. It sends a blast wave traveling at about a tenth of the speed of light ripping through the gases, jamming their layers together.

Heavier gas in inner layers stabs turbulent outcrops into lighter gas in the outer layers. Then behind the blast wave, pressure drops, stretching the gases back out for a different kind of turbulent mixing.

“It’s a hard push followed by a prolonged pull or stretch,” Musci says.

Detonation inside the supernova machine

The researchers used small amounts of a commercially available detonator (containing RDX, or Research Department eXplosive, and PETN, or pentaerythritol tetranitrate) to make the concise miniature blast that sent a clean wave through the interface between the heavier and lighter gases in the machine.

The remnants look like swirls of smoke or gas that burst outwards quickly and then fall slowly in curlicues
A black and white slow-motion gif of the blast wave making miniature supernova remnants. (Credit: Georgia Tech)

In nature, the blast wave goes out spherically in all directions, and Musci achieved a partial representation of its curvature in the machine’s blast wave. In nature and in the machine, interfaces between the gases are full of small, uneven twists and turns called perturbations, and the blast wave whacks them at skewed angles.

“That is important to growing the initial perturbation that leads to turbulence because that unevenness puts a torque on the interface between the gas layers,” Musci says.

Convolutions and curlicues ensue to make supernova remnants, which expand for thousands of years to become softer and smoother forms that stir our hearts with their splendor. To physicists, those initial twists are highly recognizable structures interesting for study: Turbulent spikes of heavy gas protruding into light gas, “bubbles” of light gas isolated in areas of heavy gas, and curls typical of early turbulent flow.

“One of the most interesting things we saw related to a mystery about supernovas—they shoot high-density gas called ejecta way out, which may help create new stars. We saw some of this gas propulsion in the device where heavy gas was propagated way out into the light gas,” Musci says.

Supernova remnants perpetually expand at speeds of hundreds of miles per second, and the new machine could help refine calculations of those speeds and help characterize remnants’ changing forms. The Crab Nebula’s supernova was recorded in the year 1054 by Chinese astronomers, but for many other remnants, the machine could also help calculate their moment of birth.

The machine’s insights would apply in reverse to help with the development of nuclear fusion energy. The process called inertial confinement fusion applies extreme force and heat from the outside inward evenly onto a tiny area where two isotopes of hydrogen gas are layered upon each other, one denser than the other.

The layers are forced together until the atoms’ nuclei fuse, unleashing energy. Fusion researchers are striving to eliminate turbulent mixing. What is beautiful in the supernova makes nuclear fusion less efficient.

Going forward, Musci plans to collaborate with Lawrence Livermore National Laboratory to compare the machine’s gas patterns with actual data on supernova remnants.

The research appears in The Astrophysical Journal . The Department of Energy’s Fusion Energy Sciences program funded the research. Any findings, conclusions, or recommendations are those of the authors and not necessarily of the Department of Energy.

Source: Georgia Tech
